Pass-Through Configuration
The Video Generator System is designed with versatility in mind, offering multiple configurations to cater to a wide range of testing and development needs in automotive display systems.
Pass-Through Configuration:
In the pass-through setup, the system acts as an intermediary between your laptop and the display of interest. It mirrors the screen on your laptop, converting the image into the appropriate video format via the VGS, and then sends it to the target display. This setup is
ideal for scenarios where real-time interaction and control are essential.
Pass-Through Uses:
Graphics Development:
Enables developers to instantly view and adjust graphics on the actual display hardware.
Test Benches:
Simplifies testing setups by providing a direct connection for functional testing.
Waveform and Power Sequence Measurements:
Allows precise control for electrical measurements and analysis.
Function Checks:
Facilitates quick verification of display functionalities and features.
Optical Measurements:
Provides accurate rendering necessary for assessing display quality and performance.
Demonstrations:
Ideal for showcasing features and capabilities during presentations or client demos.
DRIVE/VGS Advantages:
Immediate Feedback:
Real-time display of content aids in rapid development and testing cycles.
Ease of Integration:
Simple connection with existing laptops and devices without the need for complex configurations.
Versatility:
Supports a wide range of applications from development to demonstration.
High Compatibility:
Works seamlessly with various display types and formats.
Driving solutions for a wide range of applications:
- System Test Benches
- HIL Benches
- Software Test Benches
- ENV Lab and EMC Lab
- Waveform Measurements
- Power Sequence Measurements
- Proto Checks
- Eng Optical Check
- Mfg EOL
- Mfg Audible Noise Station
- Mfg Optical Station
- Customer Demos
- Tool Demos
